Power, Speed and Versatility for Your Lab

Medit T-Series

Introducing the Next Generation of 3D Dental Scanners: Our T-Series

Medit represents the apex in 3D dental scanning. With unsurpassed speed, accuracy and reliability, Medit helps you rediscover your productivity. The T-Series' new powerful scan engine and affordable pricing are the perfect fit for performance enthusiasts and entry-level users, helping your lab rediscovering productivity thanks to its convenient design and high-tech features.

Superfast Scanning

High Accuracy

Open Type Scanners

Automated Impression Scanning

High-resolution Cameras

Accuracy of the Scanner is Where It All Starts in CAD/CAM

The most demanding bridges, implants and bar designs require the highest accuracy. Using state-of-the-art blue light scanning technology, the T-Series is able to capture the highest-quality scans with high accuracy. Our 3D dental scanners fulfill various industry standards, including ISO 12836, ANSI/ADA standard No. 132 and VDI 2634, with regards to accuracy.

7 microns

     ISO 12836

Advanced Data Processing and High Resolution Cameras

The Medit T-Series has revolutionized data precision with state-of-the-art software technology, high-resolution cameras, and blue light scanning technology. The latest technology with an advanced new camera system with dual 2.0 MP resolution offers exceptional performance and scan data quality. Our new 3D scanner series thus presents brilliance of clarity for your work while saving precious time and money by minimizing trial and error to adjust restoration fits.

Sharper edges and crisper details from T-Series scanners

The Dental Industry's Fastest Lab Scanner

With the T500’s fast scan engine and highly efficient software algorithm, you can scan a full arch within 12 seconds or eight dies within 19 seconds. This makes Medit’s T500 the industry’s fastest 3D dental lab scanner.

12 seconds

 Full arch scanning

19 seconds

 8 single scanning

Model Free Workflow

Our impression scanning capability eliminates the need to make a plaster model. You can simply scan the impression immediately upon arrival in the lab and begin designing.

​The T-Series has earned a reputation as scanners optimized for impression scanning and our engineering team set out to increase this capability even further. The 3-axis impression arm will automatically scan both sides of an impression so you can take an auto double-sided impression scan in one step. Our 3D dental scanners provide the same level of accuracy in both model and impression scanning using optimized scanning paths for impression scans. This speeds up your workflow without compromising precision.

Automatic impression scanning

3 axis arm + auto double-sided impression

Flexible Multi-Die

Improve your workflow by scanning full arch or partials with multiple dies simultaneously. Efficient work in fewer scanning steps.

Projector Conservation Mode

When the scanner is left on but not in use, scanner life is reduced and electricity is wasted. When Medit scanner is not in use, the system automatically turns off the scan engine. As soon as it is needed, the projector automatically starts.

Auto stop - projector light is off

Auto start - projector light is on

Full Size Articulator Scanning

To reproduce the exact occlusion orientation, nothing is better than scanning the occlusion in the articulator itself. The T-Series of dental scanners has been designed to fit any articulator available on the market.

KAS jig, The Smart 3-In-One Jig

To use the KAVO, ARTEX or SAM articulators, KAS jig is the way to go. One jig supports all three.

New MARK330 and BIOART A7+ virtual articulators added for the latest exocad version.

Model & Specifications

Medit's T-Series engineering-added improvements and features build on our award-winning line of scanners.

Medit T500

Scanning volume

Scanning principle

Dimensions

Impression scanning

Weight

Light source

Connectivity

Scan speed (full arch)

Touch sensor

90mm x 72 mm x 60mm

Phase-shifting optical triangulation

290mm x 290mm x 340mm

3-axis automatic

12kg

Blue LED

USB 3.0 B type

12 sec

O

3-axis impression arm

Flexible multi-die

Color texture scan module

Articulator module

2-Axis manual impression jig

Articulator plate

KAS jig

Power

Warranty

O

O

O

X

​△

​△

AC 100~240V, 50~60Hz

4* years

O: Included      X: Unavailable      △: Optional

*  2 years warranty plus an additional 2 years of free spare parts replacement

Medit T300

Scanning volume

Scanning principle

Dimensions

Impression scanning

Weight

Light source

Connectivity

Scan speed  (full arch)

Touch sensor

90mm x 72 mm x 60mm

Phase-shifting optical triangulation

290mm x 290mm x 340mm

2-axis manual

12kg

Blue LED

USB 3.0 B type

24 sec

X

3-axis impression arm

Flexible multi-die

Color texture scan module

Articulator module

2-Axis manual impression jig

Articulator plate

KAS jig

Power

Warranty

O

O

​△

​△

AC 100~240V, 50~60Hz

2 years

O: Included      X: Unavailable      △: Optional



colLab 2017

Increase Your Productivity with State-of-the-Art Software Technology

colLab 2017

Our next-generation scan software, colLab 2017, makes the scanning workflow as productive as possible by providing Medit users with new scan strategies and optimum scan data quality.

Denture Replication

Replicate and archive existing dentures or create a surgical or radiographic guide with fast, accurate, high-quality scans from Medit T-Series scanners and colLab 2017 scan software.

Post & Core

The Post & Core scan feature allows routine dental scanning with the added feature of an impression scan to capture the deepest part of the Post & Core not usually visible in the model scan.

Partial denture

Interproximal scan data is important because the partial denture framework uses the interproximal undercut as a retention force foundation. The Partial denture framework scan makes it possible to use ‘interproximal scan’ used in ‘Orthodontic’ under scan strategy.

Advanced scanbody alignment

With the ‘Medit Certified’ Library, the Implant Scan Body alignment feature uses a new algorithm, ensuring high position accuracy and the accuracy of each re-alignment. Experience clear differences with the ‘Advanced Scanbody Alignment’ feature, particularly for implant bar scanning cases which are highly-sophisticated prostheses.

Scanning 16 dies at once

Existing multi-dies can scan 8 dies. To improve productivity, our exclusive multi-die has been redesigned to double capacity up to 16 dies.

Wax-up Bottoms Surface Scanning

Optimized functionality with wax-up bottom scanning allows scanning of both the extrados and the intrados of a wax-up for perfect copying of the pontic area and a much more accurate design.

Advanced Precise Color Texture

The latest technology captures vivid color texture scans with no need for an additional color camera. Capture hand-marked margins or notes in color with the Medit T-Series 3D dental scanners.

Various Strategies for Implant Case Scanning

The colLab 2017 software enables a single scan body to capture multiple implant locations. With enough scan bodies there is no need to scan twice to capture the base and scan body separately. An image of the scan body can be extracted from a single scan that contains both the base and scan body, thus saving time.

Double Sided Impression and Plaster Stump

Medit combines data from your stone die with data from the impression scan to provide you with the gingiva level and the accurate margins your work demands. This makes it easy to overcome the difficulty of checking the margin of preparation teeth on the impression. When you scan individual stone dies of a preparation tooth, colLab 2017 software aligns and integrates the plaster die data and the double-sided impression data.

Full Arch Tray

The T-Series has a 3-axis arm for automatic double-sided impression scanning, eliminating the need for manual reversing the image. The result is an easy and accurate double-sided impression scan and bite alignment.



Medit Link

Medit's new workflow management and communication software, Medit Link, is developed to enhance your performance. Its integrated cloud storage and open data architecture ensure that your clinic's performance is optimized. However, everyday CAD processes with real-time workflow management and communication tools will also work.
